Product Feature
All wetted parts are made of SS304
Both square and round motors available
YE3 high-efficiency motor, protection grade IP55 , Class F
Unique design can be used to transport seawater
High-quality bearing, wear-resistant mechanical seal
Have self-priming ability
Technical Parameters
Inlet/Outlet range:DN25~DN50
Flow range:4~16.5m³/h
Head range:8~ 22m
Max working pressure: 20bar
Liquid temperature:-10°C~105°C
