Product Feature
Horizontal/vertical centrifugal pump
Explosion-proof design can transport flammable and explosive liquids such as gasoline
Stainless steel overflow parts, suitable for corrosive liquids
Large flow and high lift
Both conventional and hot water types
Pull-up design is convenient for disassembly and maintenance
YE3 high-efficiency motor, protection grade IP55 , Class F
Technical Parameters
Inlet/Outlet range:DN15~DN300
Flow range:20~1200m³/h
Head range:3~ 150m
Max working pressure: 20bar
Liquid temperature:-20°C~120°C
